Картина | Модель | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
---|---|---|---|---|---|---|---|---|---|---|
Classic 32-6 | 32 | 2 | 3 | 6 | 230 | 50/60 | 45 | 180 | G2 | |
Classic 25-6 | 25 | 2 | 3 | 6 | 230 | 50/60 | 45 | 130/180 | G1 1/2 | |
Classic E 32-4 | 32 | 1.7 | 2 | 4 | 230 | 50/60 | 22 | 180 | G2 | |
Basic 25-4SB | 25 | 1.6 | 2.6 | 4 | 115/230 | 50/60 | 65/50/32 | 130 | G1 1/2 | |
Basic 25-4S | 25 | 1.6 | 2.6 | 4 | 115/230 | 50/60 | 65/50/32 | 130/180 | G1 1/2 | |
Basic 32-6S | 32 | 2 | 3.5 | 6 | 115/230 | 50/60 | 100/70/55 | 180 | G2 | |
Basic 20-12S | 20 | 2 | 9.5 | 12 | 115/230 | 50/60 | 270/240/160 | 150/180 | G1 | |
Basic 25-9 | 25 | 5 | 5 | 9 | 115/230 | 50/60 | 300 | 180/220 | G1 1/2 |
