Картина | Модель | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
---|---|---|---|---|---|---|---|---|---|---|
Basic 20-7S | 20 | 2 | 4.2 | 6.5 | 115/230 | 50/60 | 130/110/90 | 130/150 | G1 | |
PFM 08-36 | 40 | 8 | 36 | 58 | 220 | 50 | 1800 | 280 | DN40 | |
MHI-202 | 25/25 | 2 | 18 | 20 | 220 | 50 | 550 | 375 | Rp1-Rp1 | |
MHI-203 | 25/25 | 2 | 28 | 33 | 220 | 50 | 780 | 375 | Rp1-Rp1 | |
MHI-203Q | 25/25 | 2 | 28 | 33 | 380 | 50 | 780 | 375 | Rp1-Rp1 | |
MHI-403 | 32/25 | 4 | 28 | 33 | 220 | 50 | 780 | 371 | Rp1 1/4-Rp1 | |
MHI-403Q | 32/25 | 4 | 28 | 33 | 380 | 50 | 780 | 371 | Rp1 1/4-Rp1 | |
MHI-404 | 32/25 | 4 | 35 | 42 | 220 | 50 | 980 | 448 | Rp1 1/4-Rp1 |
