| Картина | Модель | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 20-26SZ | 20 | 7 | 18 | 26 | 230/380 | 50 | 1000/860/580 | 268 | G1 |
 |
Basic 25-20SZ | 25 | 9 | 14 | 20 | 230/380 | 50 | 1000/770/670 | 268 | G1 1/2 |
 |
Basic 20-20SZ | 20 | 5 | 16 | 20 | 230/380 | 50 | 700/550/410 | 272 | G1 |
 |
Basic 25-16SZ | 25 | 7 | 12.5 | 16 | 230/380 | 50 | 700/550/410 | 222 | G1 1/2 |
 |
Basic 20-16SZXL | 20 | 3 | 11.5 | 16 | 230 | 50 | 500/460/440 | 222 | G1 |
 |
Basic 25-12SZXL | 25 | 5 | 8.5 | 12 | 230 | 50 | 500/460/440 | 229 | G1 1/2 |
 |
Basic 25-9SZXL | 25 | 5 | 5 | 9 | 230 | 50 | 300/280/260 | 209 | G1 1/2 |
