| Картина | Модель | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Classic 20-4 | 20 | 1.5 | 2 | 4 | 230 | 50/60 | 22 | 130 | G1 |
 |
Classic S 20-7.5 | 20 | 2.5 | 4 | 7.5 | 230 | 50/60 | 70 | 130 | G1 |
 |
Mega 32-8 | 32 | 4 | 5.5 | 8 | 230 | 50/60 | 130 | 180 | G2 |
 |
Basic 25-4SB | 25 | 1.6 | 2.6 | 4 | 115/230 | 50/60 | 65/50/32 | 130 | G1 1/2 |
 |
Basic 25-12S | 25 | 2 | 9.5 | 12 | 115/230 | 50/60 | 270/240/160 | 180 | G1 1/2 |
 |
Basic 65-5F | 65 | 15 | 3 | 5 | 230 | 50/60 | 700 | 280/340 | DN65 |
 |
Basic 65-8F | 65 | 20 | 5 | 8 | 230 | 50/60 | 700 | 280/340 | DN65 |
 |
Basic 65-10F | 65 | 20 | 6.5 | 10 | 230 | 50/60 | 1000 | 300/340 | DN65 |
